Lighting Capacitor

The Lighting Capacitors are engineered to improve the performance and reliability of lighting circuits, especially in street lighting and light-duty pulse applications. By delivering stable and uniform capacitance with low ESR values, these capacitors support energy-efficient operation, extended lighting fixture life, and enhanced power factor correction. Built with high-grade materials and advanced self-healing properties, the MLC Series ensures consistent performance in harsh environments, including high-vibration and high-temperature conditions. Ideal for both residential and industrial lighting systems, these capacitors are compliant with global safety and quality standards. Available in: Dry Type in PP Can
HALCAP 42 MFD Capacitor_3 1
Lighting Capacitor

Key Features

Low ESR Value

Minimizes energy loss and heat generation, providing efficient operation for motors, fans

Self-Healing

Ensures the capacitor automatically recovers from minor electrical faults

Robust Design

Robust design withstands mechanical shocks and vibrations, making it ideal

High Insulation

Provides superior electrical isolation, preventing leakage currents and enhancing safety.

Applications

Street lighting Capacitor
Street lighting Capacitor
HID lamps Capacitor
HID lamps Capacitor
Fluorescent ballasts capacitor
Fluorescent ballasts capacitor
Industrial lighting Capacitor
Industrial lighting Capacitor

Technical Specifications

Parameter Technical Details
Capacitance Range
8.0 µF to 42.0 µF
Capacitance Tolerance
±10%
Rated Voltage VRms
440 VAC
Rated Frequence FR
50/60Hz
Safety Class
P0
Case Material
PP
Dielectric
MPP
Impregnation
Dry PU Resin (NPCB Compliant)
Terminals
Flexible wire or Faston TT on Request
Standards
As per: IS 1569
  • Related Products

“One Brand, Every Capacitor Solution – HALCAP.”

Fan Capacitor Dry / Oil

Fan Capacitor stores energy and provides extra power for the fan motors when they are running. Since a fan is expected to be operated just by the flick of a switch, it has to employ a continuous rating capacitor in series with its auxiliary winding, which stays energized as long as the fan runs. All Capacitors are designed for continuous duty and with minimum capacitance droppage which decreases the Energy Cost and also increases the lifespan of the fan motor. Available in: Dry Type in Aluminum & PP Can / Oil filled in Aluminum Can and Dry Type PP box type

Read More
Motor Run Capacitor

MOTOR RUN CAPACITOR Single-phase AC electric motors require a “Run Capacitor” to energize the second-phase winding (auxiliary coil) to create a rotating magnetic field while the motor is running. Motor run capacitors are designed for continuous duty while the motor is powered. Run capacitors are mostly polypropylene film capacitors and are energized the entire time the motor is running. Motor run capacitors are also usable for general sine wave applications such as filters, inverters, UPS devices, etc. Available in: Dry Type in PP & Aluminum Can in both Pin & Wire type

Read More
Motor Start Capacitor

MOTOR START CAPACITOR briefly increase motor starting torque and allow a motor to be cycled on and off rapidly. A start capacitor stays in the circuit long enough to rapidly bring the motor up to a predetermined speed, which is usually about 75% of the full speed, and is then taken out of the circuit, often by a centrifugal switch that releases at that speed. Afterward the motor works more efficiently with a run capacitor. StartCap 250V Series Capacitors are manufactured in PP Cylindrical case and designed for use in any Motor Start Application. Available in: Dry Type

Read More
Air Conditioning Capacitors Single/Dual

In HVAC and air conditioning systems, the AC capacitor plays a critical role in powering the compressor motor and condenser fan motor by providing the necessary electrical boost during startup. Once the capacitor delivers this initial surge of energy, it recharges and remains ready to supply additional power as needed. A dual-purpose capacitor efficiently combines the functionality of powering both the compressor motor and the condenser fan motor, optimizing space within the appliance while ensuring reliable performance. Available in: Dry Type Single as usual as dual capacitors

Read More
Power Capacitor

The Power Shunt Capacitor is a vital component in modern electrical systems, designed to enhance energy efficiency and ensure stable power distribution. These capacitors play a crucial role in power factor correction, reducing energy losses, and optimizing the performance of electrical networks. Ideal for both industrial and commercial applications, they help improve the overall reliability and efficiency of the power supply infrastructure. Available in: Aluminium Cylindrical / MS Box

Read More
MS Box Type Capacitor

The MS Box Type Capacitor is a rugged and reliable industrial component designed specifically for induction motors and agriculture equipment. It provides stable capacitance, improved power factor, and reduced energy losses, resulting in higher motor efficiency and lower operating current. Built with self-healing metallized polypropylene (MPP/MPP film) and low-loss dielectric, the capacitor maintains consistent performance even under heavy electrical load and fluctuating supply conditions. The design supports multiple terminal options such as stud, lug, and flexible wire types for easy integration into motor panels, starters, and pump control units. With a standard rating of 440V AC, 50/60Hz and compliance to IS:2993, HALCAP MS box capacitors ensure dependable long service life.

Read More
Washing Machine Capacitor

The Washing Machine Capacitors capacitors are engineered to enhance the performance and efficiency of washing machine motors. By reducing the ampere load, these capacitors ensure energy-efficient operation and prolonged motor life. Designed with advanced materials and safety features, they are ideal for both residential and commercial washing machine applications.

Read More
Lighting Capacitor

The Lighting Capacitors are engineered to improve the performance and reliability of lighting circuits, especially in street lighting and light-duty pulse applications. By delivering stable and uniform capacitance with low ESR values, these capacitors support energy-efficient operation, extended lighting fixture life, and enhanced power factor correction. Built with high-grade materials and advanced self-healing properties, the MLC Series ensures consistent performance in harsh environments, including high-vibration and high-temperature conditions. Ideal for both residential and industrial lighting systems, these capacitors are compliant with global safety and quality standards. Available in: Dry Type in PP Can

Read More
  • FAQs

Helping You Make the Right Choice

What is the primary application of the MLC Series Lighting Capacitor?
The MLC Series is designed primarily for lighting circuits, especially in street lighting and light-duty pulse applications, to improve power factor and ensure energy-efficient performance.
A low ESR (Equivalent Series Resistance) helps reduce energy losses, lowers heat generation, and ensures stable and long-lasting performance, especially in high-frequency lighting circuits.
Yes. With its high insulation resistance, self-healing properties, and resistance to vibration and high temperatures, the MLC Series is ideal for both outdoor (e.g., street lighting) and industrial environments.
The MLC Series is compliant with global safety and quality standards, ensuring reliable operation in demanding electrical applications.
